Viper® PST™ Gen II 1-6x24 VMR-2 (MOA) Reticle | 30mm Tube

LIFETIME WARRANTY.

If you ever have a problem, no matter the cause we promise to take care of you. Learn More »

When every millisecond and millimeter matter, the Viper^® PST™ Gen II delivers dependable precision trusted by competitors and MIL/LE professionals. Crisp turret adjustments. Striking clarity at every magnification. Fully loaded with features for serious tactical performance, Viper^® PST™ Gen II is your next step in mastering precision shooting—because when it matters most, nothing less will do.

Viper PST Gen II 1-6x24 Dimensions (in inches)

Lengths
L1	L2	L3	L4	L5	L6
10.83	3.0	2.19	6.85	0.50	3.44

Heights
H1	H2
1.29	1.81



Magnification	1-6x
Objective Lens Diameter	24 mm
Focal Plane	Second Focal Plane
Reticle	VMR-2 (MOA)
Eye Relief	3.8"
Field of View	112.5' - 18.8' @ 100 yds
Turret Style	Capped
Tube Size	30mm
Adjustment Graduation	1/2 MOA
Travel Per Rotation	40 MOA
Max Elevation Adjustment	160 MOA
Max Windage Adjustment	160 MOA
Parallax Setting	100 yds.
Length	10.8"
Weight	22.7 oz



XD™ Optical System	Premium optical system delivers impressive resolution, edge-to-edge sharpness, greatly reduces chromatic aberration, and guarantees bright, high-contrast images.
XR™ Lens Coatings	Premium anti-reflective coatings on all air-to-glass surfaces provide superior light transmission for exceptional clarity and low-light performance.
Illuminated Reticle	Provides precise aiming under low-light conditions.
Argon Gas Purged	Gas purged and O-ring sealed for superior fogproof and waterproof performance in the most extreme conditions.
Fast Focus Eyepiece	Allows for quick and easy reticle focusing.
Aircraft Grade Aluminum	Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
ArmorTek®	Ultra-hard exterior lens coatings defend against scratches, oil, and dirt.
Low-Glare Matte Black Anodize	Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position.
Waterproof	Designed to withstand harsh weather conditions.
Shockproof	Designed to withstand the highest levels of recoil and impact.
Fogproof	Designed to withstand a wide range of temperatures.





VMR-2 (MOA)

Hash-marked reticle using MOA or MRAD-based subtension lines for ranging, holdover, and windage corrections. Letters refer to reticle subtensions listed in chart below.

Subtension detail for Viper PST Gen II 1-6x24 riflescope with VMR-2 MOA reticle.

Included in the Box

• CR2032 battery
• Lens cloth
• Sunshade
