PULSAR AXION COMPACT XQ19 THERMAL MONOCULAR

PULSAR AXION COMPACT XQ19 THERMAL MONOCULAR

$1,699.00 AUD
$1,699.00 AUD
Sale Sold out
Tax included.
Microbolometer
Type uncooled
Resolution, Pixels 384х288
Pixel Pitch, µm 17
Sensor NETD, mK < 25
System NETD, mK < 18
Frame Rate, Hz 50
Optical Characteristics
Optical Magnification, x 1.5
Smooth Digital Zoom 1.5-6
Digital Zoom, x x1, x2, x4
Relative Aperture, D/f’ 1.0
Minimum Observation Distance, m/y 3/3.28
Eye Relief, mm 14/0.55
Exit Pupil Diameter, mm 4/0.16
Angular Field of View (Horizontal x Vertical), degree 19.5/12.3
Linear Field of View (Horizontal x Vertical), m at 100 m 34.7/21.5
Eyepiece Focus Range, Diopter +4 / -5
Detection Distance for Deer-Sized Objects, m/y 750 / 820
Display
Type AMOLED
Resolution, Pixels 640×400
Operational Characteristics
Power Supply, V 3 – 4.2
Battery Type/Capacity/Nominal Output Voltage APS 3 Li-ion Battery Pack / 3200 mAh / DC 3.7 V
External Power Supply 5 V (USB Type-C)
Battery Run Time at t=22°C, hours* 8
Degree of Protection, IP Code (IEC60529) IPX7
Operating Temperature Range, °C / °F -25 … +40 / -13 – +104
Dimensions, mm/inch 134.5x38x71 / 5.3×1.5×2.8
Weight (with battery), kg/oz 0.3 / 10.6
Video Recorder
Photo/Video Resolution, Pixels 960х600
Video/Photo Format .mp4 / .jpg
Built-in Memory 64 GB
Wi-Fi Channel**
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac

*Actual operating time will depend to what extent the Wi-Fi and built-in video recorder is used.

**Reception range may vary depending on various factors: obstacles, other Wi-Fi networks.
